Description
The C10 is configured for the unique demands of the center channel in movie soundtracks, providing exceptional dialogue reproduction and a seamless transition between the left and right front channels.
Warranty:
1-year manufacturer’s warranty
Features:
-
Rigid aluminum enclosure
-
Micro Ceramic Composite (MCC) Cone Woofers
-
1” Tweeter
-
Wall brackets
Benefits:
The performance of Revel Concerta™ on-wall loudspeakers has been extensively evaluated in a variety of on-and near-wall installations through blind listening tests in the Revel Multichannel Listening Lab.
Using proprietary 36-point anechoic measurements, Concerta on-wall speakers have been shown to deliver remarkably flat frequency response across an exceptionally wide listening area for clean, accurate sound in real-world listening rooms.
None of the competing systems tested under identical conditions performed as well. Remarkably, Revel engineers could not identify a single competing on-wall system they considered suitable for on-wall use, based on either laboratory measurements or double-blind listening tests.
With advanced drivers utilizing Micro Ceramic Composite (MCC) cones and domes, along with high-order crossovers, and housed in rigid aluminum enclosures styled to complement the look of LCD and plasma displays, Concerta on-wall systems will fill any room with brilliant, distortion-free sound from virtually any amplifier.
Concerta speakers are voice-matched for use in any combination to build movie and music systems of uncommon realism. The series includes an innovative 3-channel LCR system mounted in a single enclosure, a capable center channel speaker, a choice of satellites, and an impressive 250-watt powered subwoofer. The B120 sub can be connected directly to your system or operated wirelessly with an optional transmitter, for complete placement freedom.
All Concerta on-wall woofer, midrange, and tweeter diaphragms are constructed of Micro Ceramic Composite (MCC), a new material created by anodizing both sides of an aluminum core. Anodizing both sides of an aluminum core adds strength and stiffness – but very little weight – to a material already well suited for use in transducer diaphragms.
With appropriate hardware, it’s possible to affix virtually any compact loudspeaker to a listening room wall. Manufacturers are free to promote any model of a certain size and weight as “wall-mountable.” But very few audio manufacturers have the facilities and expertise needed to determine just how their on-wall systems will sound when placed on or near a wall.
Technical Specifications:
| Frequency Response | (±3dB) 110Hz – 21kHz |
| Height | 4-1/4″ (107mm) |
| Width | 22-15/16″ (582mm) |
| Depth | 4-1/2″ (113mm) |
| Weight | 3.1Kg |
| Crossover Frequencies | 2-1/2-Way at 400Hz and 2.2kHz |
| High-Frequency Driver Components | 1″ (25mm) tweeter with waveguide and Micro Ceramic Composite (MCC) dome |
| Low-Frequency Extension | –3dB @ 110Hz –6dB @ 100Hz –10dB @ 80Hz4Hz |
| Mid-frequency Driver Components | Dual 3″ (76mm) midrange transducers, micro-ceramic Composite (MCC) cone woofers |
| Low-frequency Driver Components | Dual 3″ (7.5 cm) micro-ceramic Composite (MCC) cone woofers |
| Sensitivity | (2.83V @ 1m, 2π anechoic) 89 dB |
| Nominal Impedance | 8 Ohms |
