Category: Speaker

JBL Stage 280W - 2 Way 8 inches In-Wall Speaker (Each)

Key Features

  • 8-inch polycellulose woofer delivers deep, punchy bass with low distortion

  • 1-inch aluminum dome tweeter provides crisp and clear high frequencies

  • Swiveling tweeter allows precise aiming for optimal soundstage

  • 2-way in-wall design ideal for home theater or multi-room audio setups

  • Slim bezel, paintable grille blends seamlessly into any dĂ©cor

  • Engineered for wide dispersion to fill the room evenly

  • High power handling suitable for dynamic movie and music playback

  • Easy installation with sturdy mounting tabs and template included

Description

JBL Stage 280W – 2 Way 8-inch In-Wall Speaker (Each)

Stage 280W

 2-way Dual 5.25″ (130mm) In-Wall Loudspeaker

For more powerful bass, the Stage 280W features an 8″ (200mm) Polycellulose cone woofer and a 1″ (25mm) Aluminum dome tweeter with an acoustic lens and HDI™ waveguide. A visually discrete zero bezel grille and easy installation allow these speakers to be heard and not seen. Elements including baffles with acoustic smoothing, acoustic lens tweeters, and patented High-Definition Imaging (HDItm) waveguide geometry have been incorporated into the design to ensure that the sound is clear and accurate.

1″ (25mm) Aluminum dome with High-Definition Imaging (HDI™) waveguide

8″ (200mm) Polycellulose cone woofer

Premium air-core inductors and mylar cap capacitor crossover network components ensure that sound remains dynamic at all listening levels.

 FEATURES

  • Rigid Baffle design with acoustic smoothing for improved transducer integration
  • XL-2 installation system compatible with up to 2” (50mm) thick wall/ceiling material.
  •  Zero bezel metal grille installs flush to the wall or ceiling for a clean, inconspicuous appearance

 Stage 280W

For more powerful bass, the Stage 280W features an 8″ (200mm) Polycellulose cone woofer and a 1″ (25mm) Aluminum dome tweeter with an acoustic lens and HDI™ waveguide. A visually discrete zero bezel grille and easy installation allow these speakers to be heard and not seen. Elements including baffles with acoustic smoothing, acoustic lens tweeters, and patented High-Definition Imaging (HDItm) waveguide geometry have been incorporated into the design to ensure that the sound is clear and accurate.



Specifications

High Frequency Transducer
1″ (25mm) Aluminum dome with High-Definition Imaging (HDI™) horn
Low Frequency Transducer
8″ (200mm) Polycellulose cone woofer
Recommended Amplifier Power (Full Range)
20-120W RMS
Frequency Response
42Hz-25kHz (-6dB on-axis)
Sensitivity (2.83V@1m)
90dB
Nominal Impedance
8ohm
Crossover Frequency
1700Hz
Inputs
Nickel-plated spring-loaded connectors
Grille Dimensions
H 15.7in (400mm) x W 10.5in (266mm)
Cutout Dimensions
H 14.6in (372mm) x W 9.4in (238mm)
Mounting Depth
3.9in (98mm)
Product Weight (Kg)
2.8Kg
Shipping Carton Dimensions
L 17.8in (453mm) x W 12.5in (318mm) x H 5.5in (140mm)
Shipping Carton Weight
8.38lbs (3.8Kg)
