Emotiva XPA-2 Gen3 – 2 Channel Audiophile Power Amplifier

Key Features

High-Performance Two-Channel Power Amplifier
Designed for stereo systems or front-channel amplification in home theatre setups, delivering clean, powerful sound with authority and precision.
Modular Gen3 Amplifier Architecture
Independent amplifier modules for each channel reduce crosstalk and ensure consistent performance across both channels.
High-Current Class AB Amplification
Provides refined, musical power with low distortion and excellent dynamic control.
Massive Shared Power Supply
Oversized toroidal transformer with generous energy storage delivers strong transient response, stable power delivery, and headroom.
Balanced and Unbalanced Inputs
Equipped with both XLR and RCA inputs for flexible integration with a wide range of preamplifiers and audio sources.
Independent Channel Operation
Each channel operates autonomously, improving separation and system stability.
Stable with Low-Impedance Speakers
Capable of driving demanding speaker loads while maintaining control, detail, and dynamic authority.
Advanced Protection Circuitry
Built-in safeguards against short circuits, overheating, and overload ensure durable and reliable long-term performance.
Efficient Thermal Management
Large heat sinks and smart cooling design maintain optimal operating temperatures during extended listening sessions.
Heavy-Duty Steel Chassis Construction
Rigid enclosure reduces vibration and electromagnetic interference for improved sonic purity.
Ideal for Audiophile Stereo Systems
Engineered to satisfy high-end stereo enthusiasts seeking clean power, detail, and musical finesse.

Description

Power Output	300 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven. 550 watts RMS/channel; 20 Hz – 20 kHz; THD<0.2%; 4 Ohms; one channel driven. 300 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven. 490 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven.
Power Bandwidth (at rated power; 4 Ohm – 8 Ohm load)	20 Hz to 20 kHz (+ / – 0.1 dB).
Broad Band Frequency Response	5 Hz to 80 kHz +0/-2 dB.
THD + noise	< 0.005%; at 100 watts RMS; 1 kHz; 8 Ohms.
Signal to Noise Ratio (8 Ohm load)	117 dB; ref FTC rated power; unbalanced input (A-weighted). > 91 dB; ref 1 watt; unbalanced input (A-weighted).
Minimum Recommended Load Impedance (per channel)	4 Ohms (which equals one 4 Ohm load or two paralleled 8 Ohm loads).
Damping Factor (8 Ohm load)	> 500.
Input Sensitivity (for rated power; 8 Ohm load)	1.5 V.
Gain	29 dB.
Maximum Power Consumption	1,000 watts. Note: The values shown refer to the amount of power the amplifier would consume while playing test tones continuously, on all channels, at full power, into a load bank. Therefore, they are not at all characteristic of what you would expect when playing music or the soundtrack from a movie. Normal audio signals are dynamic, so the amount of power they require from second to second varies widely, and the average is far lower than this. With normal content, even playing very loudly, one of our amplifiers will consume far less power than indicated in the chart, so these values should not be considered to be a circuit requirement for normal operation.
Input Impedance	33 kOhms (balanced). 23.5 kOhms (unbalanced).

Input Connections	(High-Powered Single Channel Modules): Unbalanced (RCA); balanced (XLR); one each per channel, independently selectable.
Input Connections (Stereo Modules)	2 Unbalanced (RCA); 2 balanced (XLR); two per channel, independently selectable.
Speaker Output Connections	Audiophile-grade, gold-plated, 5-way binding posts.
Trigger	Trigger Input: 5 – 12 V (AC or DC); <10 mA input current required. Trigger Output: 12 VDC; can drive any load up to 120 mA.

Power Requirements	Between 100 VAC and 250 VAC @ 50 / 60 Hz (automatically detected).

Standby	push button (halo ring changes color to indicate Standby or On).
Status LEDs	one per channel; blue. Status LEDs change to red to indicate a fault condition.

AC Power switch	rocker switch (switches the AC main power).
Status LEDs switch	disables front panel Status LEDs and dims Standby button halo.
Input selector switches (one per channel)	metal toggle switches; select between balanced and unbalanced inputs.
Circuit Breaker	press button to reset the circuit breaker.

Protection	The XPA Gen3 is protected against excessive operating temperature, shorted speaker connections, ground faults, and other common fault conditions.

Dimensions	17” wide x 8” high x 19” deep (unboxed; including feet). 17” wide x 7” high x 19” deep (unboxed; without feet). 24-1/2” wide x 12” high x 24-3/4” deep (boxed).
Weight	35.5 lbs (unboxed). 40.5 lbs (boxed).
