Emotiva BasX A2 - 2 Channel Stereo Power Amplifier

2-Channel Stereo Power Amplifier
Designed to provide solid, clean power for stereo systems and front-channel amplification in home audio setups.
Class AB Amplification
High-current Class AB output stage delivers natural, musical sound with low distortion and good dynamic control.
Robust Power Supply
Generous power supply provides stable output and consistent performance across both channels, even under demanding loads.
Unbalanced RCA Inputs
Standard line-level RCA inputs allow easy connection to a wide range of preamplifiers, receivers, and audio sources.
Stable Speaker Driving Capability
Capable of driving a variety of speaker loads with confidence and accuracy.
Efficient Thermal Management
Built-in heat dissipation design ensures reliable operation over extended listening periods.
Protection Circuitry
Includes safeguards against short circuits, overheating, and overload to protect both amplifier and connected speakers.
Solid Metal Chassis Construction
Rigid steel enclosure reduces vibration and electrical interference for improved sonic stability and longevity.
Simple and Intuitive Setup
Straightforward connections and controls make it easy to integrate into existing audio systems.
Affordable Entry to High-Performance Amplification
Offers a high-value option for users seeking quality stereo power without complexity.

Description

Power Output	(Two Channels Driven) 160 watts RMS per channel; 20 Hz – 20 kHz; THD < 0.1%; into 8 Ohms. 250 watts RMS
per channel	1 kHz; THD < 1%; into 4 Ohms.
Power Bandwidth (at rated power; 4 Ohm – 8 Ohm load)	20 Hz to 20 kHz (+ / – 0.07 dB)
Broad Band Frequency Response	10 Hz to 80 kHz +0/-1.8 dB
THD + noise	< 0.02% (A-weighted); ref rated power
Signal to Noise Ratio (8 Ohm load)	> 112 dB; ref rated power; (A-weighted).
Minimum Recommended Load Impedance (per channel)	4 Ohms (which equals one 4 Ohm load or two paralleled 8 Ohm loads).
Damping Factor (8 Ohm load)	> 500.
Input Sensitivity (for rated power; 8 Ohm load)	1.2 V.
Gain	29 dB.
Input Impedance	27 kOhms.

Input Connections	Unbalanced (RCA); one each per channel.
Speaker Output Connections	Audiophile-grade 5-way binding posts.
Trigger	Trigger Input: 5 – 12 V (AC or DC); <10 mA input current required. Trigger Output: 12 VDC; can drive any load up to 120 mA.

Power Requirements	115 VAC or 230 VAC @ 50 / 60 Hz (automatically detected).

Standby	push button.
Status LEDs	one per channel; blue.
Status LEDs	change to red to indicate a fault condition.
Standby LED	amber.

AC Power switch	rocker switch (switches AC main power).
Status LEDs switch	disables front panel Status LEDs.
Auto On	Source detectible auto on

Protection	The BasX A2 is protected against excessive operating temperature, shorted speaker connections, ground faults, and other common fault conditions.

Dimensions	17” wide x 4” high x 15-1/2” deep (not including connectors). 21-1/2” wide x 8” high x 21” deep (boxed). Weight: 25.2 lbs (unboxed) 33 lbs (boxed)
