Yamaha VXS3S 3.5" Dual SR-Bass™ Subwoofer

Key Features

Compact 3.5-inch dual driver subwoofer designed to enhance low-frequency performance in small spaces
Uses SR-Bass™ (Symmetrically Balanced) technology for deeper, extended bass from a compact enclosure
Passive subwoofer that pairs with an external amplifier or AV receiver for power
Symmetrical dual driver design reduces cabinet vibration and distortion
Low-profile and shallow mounting depth ideal for discreet installation under cabinets, in shelves, or behind furniture
Suitable for background music systems, distributed audio zones, and home theater setups requiring compact bass reinforcement
Designed to complement Yamaha VXS series speakers and other small satellite speakers
Durable build quality for long-term reliability
Easy integration into existing systems with standard speaker wire connections

Description

VXS series “S” model subwoofers which are an ideal match for VXS and VXC series speakers, smoothly extending the low-frequency range with unparalleled sonic quality for bigger, close-to-reality musical reproduction. Although no larger than a compact surface-mount speaker the VXS3S delivers robust, spontaneously-sounding low-end reinforcement., while the VXS10S and VXS10ST make even more low-frequency power available for situations that require maximum bass authority.

Warranty 1-year manufacturer’s warranty

Key Features:

Versatile subwoofer supports low and high impedance systems
Sound and size ideally matched to the VXS1ML
SR-Bass™ technology delivers solid bass in a compact unit
Satellite connectors for easy setup
Dedicated wall/ceiling mount hardware supplied
Black and white models available
Paintable enclosures and grilles
Recommended satellite speakers: VXS1ML

Benefits of Yamaha VXS3S 3.5″ Dual SR-Bass™ Subwoofer:

Wide Array of Models to Cater to All Low-frequency Needs

Luxurious bass response can enhance musical presence and realism manifold. Yamaha offers the VXS3S for smoothly extended low-end power, and the VXS10S and VXS10ST for applications that require maximum bass impact. Choose the model that is best suited according to the size of the system and the full-range speakers used.

High-performance Full-range Driver

A number of methods are used to enhance low-frequency response in speaker enclosures. Original Yamaha SR-Bass™ technology employed in the VXS3S suspends a four-sided diaphragm on only one of its sides, using the resonance of the diaphragm to enhance the system’s low-frequency output. It doesn’t come with any constraints on the shape and materials used for the diaphragm, making SR-Bass™ technology applicable to a wide range of speaker designs, including compact models. In bass reflex designs, a tuned port in the enclosure boosts low frequencies releasing from the rear of the speaker unit. The VXS10S adopts this method, specializing in more powerful low-frequency reproduction. One constraint with this approach is that as the enclosure becomes smaller or thinner, the size of the port must be reduced accordingly, resulting in increased resistance and correspondingly reduced bass enhancement. Bass reflex designs are not always the best fit for compact enclosures.

Passive radiator designs avoid the use of a port, giving a boost to bass response with a tuned passive “drone cone.” The passive radiator method is apt for compact enclosures, but the passive cone tends to be heavy, requiring some form of the firm and durable suspension that can adversely impact efficiency. The directivity of the passive radiator also casts limitations on where and how the system can be installed. Yamaha offers 2 choices. That is compact VXS3S and powerful VXS10S. You can select the best model for your application.

Satellite Connectors Optimize Balance

The VXS3S and VXS10S have satellite connectors on the rear panel, cutting down the number of amplifier channels required to get a system operational. And since the VXS3S and VXS10S support high-impedance connections, it is possible to connect low-impedance satellites while the subwoofer is connected to a high-impedance system, for example. A built-in high-pass filter is auto-applied to the satellite speakers, rendering exceptionally smooth, natural frequency crossover from the subwoofer to satellites.

Flexible Installation Options

In addition to the supplied wall-mounting hardware, a wide array of optional hardware allows VXS series “S” models to be mounted, while factoring in preferences and convenience. The VXS10S can be placed on the floor or mounted on a wall or ceiling, while the VXS3S additionally allows flush ceiling mounting.

Surface-mount (VXS3S) – *Requires the supplied bracket and hardware.
Ceiling-mount (VXS3S) – *Requires the optional CMA3S bracket.
Surface-mount (VXS10S/VXS10ST) – *Requires the supplied bracket and hardware.
Ceiling-mount (VXS10S/VXS10ST) – *Requires the optional UB-DXR8 bracket

Technical Specifications of Yamaha VXS3S 3.5″ Dual SR-Bass™ Subwoofer:

Brand & Model #	Yamaha VXS3S
Speaker Type	SR-Bass™ type Subwoofer
Frequency range (-10dB)	65Hz-180Hz
Components	LF – 3.5″ Cone
Power rating	NOISE: 20W PGM: 40W PEAK: 80W
Nominal Impedance	8Ω
Satellitel Impedance	8Ω load per satellite output recommended *1
Transformer Taps	100V – 15W, 7.5W, 3.8W 70V – 15W, 7.5W, 3.8W, 1.9W
SPL	Sensitivity (1W; 1m on axis): 79dB SPL 3 Peak (Calculated): 92dB SPL 4
I/O Connectors	TERMINAL BLOCKS(4pin) Input: +/-, Loop-thru: +/-, TERMINAL BLOCKS(8pin) Satellite output:+/- (ST1～ST4)
Protection Circuit	Load Protection – Full-range power limiting for protecting network and transducers
Shape	Rectangular
Cabinet Material	ABS
Finish	VXS3SB:Black (approximate value:Munsell N3) VXS3SW:White (approximate value:Munsell N9)
Dimensions	W – 322mm (12.7″) 5 H – 162mm (6.4″) 5 D – 118mm (4.6″) *5
Weight	2.7kg (6.0 lbs) *5
Accessories	Mounting bracket, Safety wire, Spacer, Screw, Masking sheet
Packaging	Packaged each
Certificate	NFPA70, CE, RoHS

*1 Satellite impedance: When connecting 8Ω satellites, the combined impedance is 4Ω (when connecting four satellites) or 3.5Ω (when connecting two satellites).
*2 Satellite impedance: Impedance lower limit (per satellite output) VXS10S/10SW: 4Ω, VXS10ST/10STW: 8Ω
*3: VXS10S / VXS10ST:Half space (2π), VXS3S:Full-space (4π)
*4: Calculated based on power rating and sensitivity, exclusive of power compression
*5: Speaker only
