Description
The M8 is ideal as an inconspicuous surround loudspeaker or front-channel loudspeaker, whether wall-mounted or placed on a shelf. Voice-matched for use in any combination, Concerta speakers build movie and music systems of uncommon realism.
Warranty:
1-year manufacturer’s warranty
Features:
-
Rigid aluminum enclosure
-
Micro Ceramic Composite (MCC) Cone Woofers
-
1” Tweeter
-
Wall brackets
Slender looks, seamless sound
The Concerta M8 is Revel’s most compact on-wall speaker. Despite its small size, it delivers the open, accurate sound Revel is known for.
During development, Revel’s engineers evaluated the M8 in a variety of on- and near-wall installations, measuring the on- and off-axis response in an anechoic chamber from dozens of different listening angles. They balanced that with a series of double-blind listening tests performed by a panel of experts in the company’s Multichannel Listening Lab. The M8 consistently delivered flat frequency response across an exceptionally wide listening area. That translates to clear, realistic sound in real-world listening rooms.
The M8’s woofer and tweeter diaphragms are made of Micro Ceramic Composite (MCC), a proprietary material created by anodizing both sides of an aluminum core. This adds strength and stiffness, but very little weight, which is exactly what you want for accurate sound reproduction.
The speaker’s rigid aluminum enclosure is styled to complement the look of the latest flatscreen TVs.
Technical Specifications:
| Height | 11.6″ (29.6 cm) |
| Width | 4.3″ (10.8 cm) |
| Depth | 4.5″ (11.4 cm) |
| Weight | 1.6Kg |
| Crossover Frequencies | 2-Way at 2.2kHz |
| Input Sensitivity | 400mV (full power)/20k Ohms (balanced); 14k Ohms (unbalanced) |
| Inputs | Balanced (XLR), unbalanced (RCA) |
| High-Frequency Driver Components | 1″ (2.5 cm) micro-ceramic composite (MCC) dome tweeter |
| Low-Frequency Extension | –3dB @ 110Hz –6dB @ 100Hz –10dB @ 90Hz4Hz |
| Low-frequency Driver Components | Dual 3″ (7.5 cm) micro-ceramic Composite (MCC) cone woofers |
| Sensitivity | 88 DB |
| Nominal Impedance | 8 Ohms |
