Description
As the left and right speakers in a music system, or perfectly matched to the Concerta C10 in a home theater system, the M10 delivers superb music reproduction and realistic, all-encompassing movie sound to rooms of virtually any size.
Warranty:
1-year manufacturer’s warranty
Features:
-
Rigid aluminum enclosure
-
Micro Ceramic Composite (MCC) Cone Woofers
-
1” Tweeter
-
Wall brackets
-
Three different bases included
-
Option STANDM10 loudspeaker stand
Benefits:
Slender looks, seamless sound
If you want a slender, stylish speaker system to complement your skinny flatscreen TV, Revel’s Concerta M10 on-wall speaker is a brilliant choice, especially if you care about accurate sound.
During development, Revel’s engineers evaluated the M10 in a variety of on- and near-wall installations, measuring the on- and off-axis response in an anechoic chamber from dozens of different listening angles. They balanced that with a series of double-blind listening tests performed by a panel of experts in the company’s Multichannel Listening Lab. The M10 consistently delivered flat frequency response across an exceptionally wide listening area. That translates to clean, accurate sound in real-world listening rooms.
The M10’s woofer, midrange, and tweeter diaphragms are made of Micro Ceramic Composite (MCC), a proprietary material created by anodizing both sides of an aluminum core. This adds strength and stiffness, but very little weight, which is exactly what you want for accurate sound reproduction.
The speaker’s rigid aluminum enclosure is styled to complement the look of the latest flatscreen TVs.
Build a complete Revel system
A pair of M10s will create an unobtrusive but highly musical 2-channel system. If you’re interested in a voice-matched surround sound system, check out these other models from Revel’s Concerta series:
Center channel: Concerta C10
Subwoofer: Concerta2 B10
Technical Specifications:
| Height | 22.9″ (58.2 cm) |
| Width | 4.3″ (10.8 cm) |
| Depth | 4.5″ (11.4 cm) |
| Weight | 3.1Kg |
| Crossover Frequencies | 2-1/2-Way at 400Hz and 2.2kHz |
| Input Sensitivity | 400mV (full power)/20k Ohms (balanced); 14k Ohms (unbalanced) |
| Inputs | Balanced (XLR), unbalanced (RCA) |
| High-Frequency Driver Components | 1″ (2.5 cm) micro-ceramic Composite (MCC) cone tweeter |
| Low-Frequency Extension | –3dB @ 110Hz –6dB @ 100Hz –10dB @ 90Hz4Hz |
| Mid-frequency Driver Components | Dual 3″ (7.5 cm) micro-ceramic Composite (MCC) cone woofers |
| Low-frequency Driver Components | Dual 3″ (7.5 cm) micro-ceramic Composite (MCC) cone woofers |
| Sensitivity | 89 dB |
| Nominal Impedance | 8 Ohms |
