Reloop Turn 3 Turntable

TURN3 MK2

Premium HiFi-turntable with digital USB-Audio Interface

Over 25 years of experience

With over 25 years of experience in the DJ and pro audio industry, Reloop is one of the market leaders for DJ, HiFi turntables and accessories. Especially developed for music lovers and sound purists, Reloop presents the HiFi turntable TURN 3 MK2.

Quiet DC drive

The heart of the TURN 3 MK2 is a synchronous belt drive, powered by a low-vibration DC motor – motor noises are thus hardly perceptible.

Electronic speed control for 33, 45 & 78 rpm

The TURN 3 MK2 eliminates the need to change the drive belt. Depending on the choice of record, the desired speed can be conveniently set to 33, 45 or 78 RPM with the large speed control knob. Even shellac records can be played back when using a suitable pick-up system.

Revised tonearm construction

The redesigned tonearm, especially developed for the TURN 3 MK2, offers a remarkably good tracking performance for an outstanding sound experience.

Anti-skating wheel

The anti-skating adjustment of the tonearm can be conveniently set via a special wheel for perfect tracking adjustment.

Headshell connection

The headshell connection is equipped with a GM/SME mechanism. This allows the preferred headshells and systems to be individually mounted on the tonearm.

USB recording function

The integrated USB interface allows you to digitise your favourite records directly on PC/MAC in CD quality. Ideal for listening on the go or for archiving your cherished vinyl collection.

Semi-automatic stop

With the integrated semi-automatic control, the TURN 3 MK2 automatically stops at the end of a record. In addition, it is possible to deactivate the semi-automatic control in order to control the playback manually.

Shock-absorbing feet

Decoupled, shock-absorbing feet help to prevent any unwanted vibrations and guarantee a clean audio signal.

Precision-manufactured die-cast aluminium turntable

The turntable of the TURN 3 MK2 is made of a heavy aluminium die-cast construction, which provides a solid and consistent rotational performance. The heavy and precise fabrication also adds additional mass, helping to eliminate unwanted resonances for the best possible acoustic results.

Solid base with piano finish

The sturdy and solid MDF base, covered with a fine piano finish, ensures a detailed and warm sound image.

Immediate listening pleasure with a hi-tech Ortofon cartridge

The TURN 3 MK2 is equipped with a pre-assembled, high-quality Ortofon 2M Red pick-up system.

Gold-plated connections

The gold-plated connections guarantee purest signal transmission and ensure maximum flexibility; all cables are detachable.

High-end pre-amplifier

Equipped with a high-end pre-amp, the Reloop TURN 3 MK2 can be easily and directly connected to an amplifier, even without a phono input. A separate pre-amplifier is thus not necessary.

Reloop TURN 3 MK2
A class of its own.

The Reloop TURN 3 MK2’s improved construction and carefully selected components deliver exquisite sound characteristics at an extraordinary price that surprises and delights audiophiles in equal measure!

RELOOP TURN 3 MK2

PREMIUM HIFI-TURNTABLE WITH DIGITAL USB-AUDIO INTERFACE

• Authentic HiFi turntable with digital USB-Audio Interface
• Pre-installed Ortofon 2M Red cartridge
• Low-vibration DC motor

With over 25 years of experience in the DJ and pro audio industry, Reloop is one of the market leaders for DJ, HiFi turntables and accessories. Especially developed for music lovers and sound purists, Reloop presents the HiFi turntable TURN 3 MK2.

Quiet DC drive

The heart of the TURN 3 MK2 is a synchronous belt drive, powered by a low-vibration DC motor – motor noises are thus hardly perceptible.

Revised tonearm construction

The redesigned tonearm, especially developed for the TURN 3 MK2, offers a remarkably good tracking performance for an outstanding sound experience.

Headshell connection

The headshell connection is equipped with a GM/SME mechanism. This allows the preferred headshells and systems to be individually mounted on the tonearm.

Electronic speed control for 33, 45 & 78 rpm

The TURN 3 MK2 eliminates the need to change the drive belt. Depending on the choice of record, the desired speed can be conveniently set to 33, 45 or 78 RPM with the large speed control knob. Even shellac records can be played back when using a suitable pick-up system.

Semi-automatic stop

With the integrated semi-automatic control, the TURN 3 MK2 automatically stops at the end of a record. In addition, it is possible to deactivate the semi-automatic control in order to control the playback manually.

USB recording function

The integrated USB interface allows you to digitise your favourite records directly on PC/MAC in CD quality. Ideal for listening on the go or for archiving your cherished vinyl collection.

High-end pre-amplifier

Equipped with a high-end pre-amp, the Reloop TURN 3 MK2 can be easily and directly connected to an amplifier, even without a phono input. A separate pre-amplifier is thus not necessary.

Precision-manufactured die-cast aluminium turntable

The turntable of the TURN 3 MK2 is made of a heavy aluminium die-cast construction, which provides a solid and consistent rotational performance. The heavy and precise fabrication also adds additional mass, helping to eliminate unwanted resonances for the best possible acoustic results.

Anti-skating wheel

The anti-skating adjustment of the tonearm can be conveniently set via a special wheel for perfect tracking adjustment.

Gold-plated connections

The gold-plated connections guarantee purest signal transmission and ensure maximum flexibility; all cables are detachable.

Shock-absorbing feet

Decoupled, shock-absorbing feet help to prevent any unwanted vibrations and guarantee a clean audio signal.

Solid base with piano finish

The sturdy and solid MDF base, covered with a fine piano finish, ensures a detailed and warm sound image.

Immediate listening pleasure with a hi-tech Ortofon cartridge

The TURN 3 MK2 is equipped with a pre-assembled, high-quality Ortofon 2M Red pick-up system.

The Reloop TURN 3 MK2’s improved construction and carefully selected components deliver exquisite sound characteristics at an extraordinary price that surprises and delights audiophiles in equal measure!

FEATURES

• Authentic HiFi turntable with precision belt drive
• Supplied with pre-assembled Ortofon 2M Red cartridge
• Optimised tonearm design for optimal tracking accuracy with flexible SME mounting
• Integrated high-quality preamplifier, can be switched on/off (phono/line output)
• USB recording function: recording and digitalisation of vinyl via a simple USB connection for PC/Mac
• Semi-automatic stop function (can be activated optionally)
• Manual tonearm lift for analogue playback pleasure
• Low-vibration DC motor
• Integrated motor control with a large speed selector switch (33/45/78 RPM)
• External DC power supply for trouble-free operation (100-230 V / 12 V / 500 mA)
• Precision-machined die-cast aluminium platter for resonance optimisation
• Infinitely adjustable anti-skating system with rotary wheel for optimum tracking accuracy
• Gold-plated, anti-corrosion connectors (all cables removable)
• Special turntable feet for effective decoupling
• High-gloss piano-finish cabinet
• On/Off switch on the back of the unit
• Incl. Ortofon 2M Red cartridge pre-mounted on headshell, counterweight, dust cover incl. hinges, felt mat, aluminium turntable, 7″ aluminium adapter, RCA & USB cable and international power supply (UK/EU/US)



Specifications

TURN 3 MK2

Type of turntable	Belt drive
Motor	DC Motor
Rotation speeds	33 1/3, 45 & 78
Wow and flutter	0.2% WRMS
Analogue Output	Phono / Line, switchable
Connections	RCA Audio output (gold-plated), USB type B
Phono Output Level	4.0 mV (with Ortofon 2M Red)
Line Output Level	224 mV (with Ortofon 2M Red)
Tone Arm type	Straight
Effective Arm Length	223.6 mm
Effective tonearm mass	21.4 g
Overhang	18.6 mm
Tracking force Range	18 mN
Platter diameter	300 mm
Anti-Skating adjustment	Yes
Type of cartridge	MM (Ortofon 2M Red)
Power consumption	6W
S/N	>60 dB or higher
USB Audio	Output with 48 kHz / 16-bit
USB Funktion	USB rec. function
Supported Operating System	Windows & Mac
Dimensions	450 x 352 x 138.7 mm (incl. Dust cover)
Weight	6.5 kg

Ortofon 2M Red

Output voltage at 1000 Hz, 5cm/sec.: 5,5 mV
Channel balance at 1 kHz: 1,5 dB
Channel separation at 1 kHz: 22 dB
Channel separation at 15 kHz: 15 dB
Frequency range at – 3dB: 20-22.000 Hz
Frequency response: 20-20.000 Hz + 3 / – 1 dB
Tracking ability at 315Hz at recommended tracking force: 70 μMm
Compliance, dynamic, lateral: 20 μMm
Stylus type: Elliptical
Stylus tip radius: r/R 8/18 μMm
Tracking force range: 1,6-2,0g (16-20 mN)
Tracking force, recommended: 1,8 g (18 mN)
Tracking angle: 20°
Internal impedance, DC resistance: 1,3 kOhm
Internal inductance: 700 mH
Recommended load resistance: 47 kOhm
Recommended load capacitance: 150-300 pF
Cartridge colour, body/stylus: Black/Red
Cartridge weight: 7.2 g
