Key Features

• High-Torque Direct-Drive Motor

Quartz-locked, brushless DC motor delivers fast start-up and stable rotation — ideal for DJs and serious vinyl users.

• Fast Start-Up Time (0.3 Seconds)

Reaches 33⅓ RPM almost instantly, perfect for cueing, beatmatching, and club-style performance.

• Adjustable Pitch Control

Select pitch ranges of ±8%, ±16%, or ±50%, plus a pitch-reset button for instant return to exact standard speed.

• Heavy-Duty Build & Vibration Isolation

Thick, die-cast chassis with damping materials reduces resonance and maintains stable playback even under heavy use.

• S-Shaped Tonearm

Gimbal-mounted tonearm with adjustable tracking force and anti-skate. Compatible with a wide range of cartridges.

• Aluminium Die-Cast Platter

Heavy 332 mm platter improves rotational stability and minimizes wow and flutter.

• Professional Analogue Output

Standard RCA output (no built-in phono preamp). Works with any external phono stage or mixers with a phono input.

• Supports 33⅓ and 45 RPM

Covers all standard record formats.

• Strong Build Quality

Weighs around 14.6 kg — extremely stable and durable for DJing and high-quality home listening.

• Classic “Club-Style” Layout

Designed with the same usability and feel DJs expect from industry-standard turntables.

Description

Pioneer PLX-1000-K Direct-Drive Turntable (Black)

A reborn classic

The PLX-1000 is precision-engineered for the booth, drawing on 50 years’ experience of making high-end turntables. The result is a familiar layout with some next-generation improvements, including a high-torque direct drive system, multi-pitch control, club-grade build and sound quality, and detachable

Turn the tables

The high-torque direct drive ensures stable rotation and exceptional control – and it reaches 33⅓ rpm in just 0.3 seconds thanks to a starting torque of 4.5kg/cm (or more).

Excellent sound design

The PLX-1000’s heavy-mass, die-cast zinc chassis prevents resonance and vibrations. The lower part of the unit is reinforced with 8mm-thick resin, plus 9mm-thick, vibration-damping material at the base. Plus, the rubber-insulated tone arm reduces howling effects, while rubber and springs on the dampening parts of the insulator absorb external vibrations.

Pick up the pace

Multi-tempo control lets you instantly pick up or slow down the track to ±8%, ±16% and ±50%, while a simple reset button instantly reverts to ±0%.

Flexible connectivity

Interchangeable power and audio cables can be easily connected and replaced, and pro-grade gold-plated RCA jacks ensure low impedance and an amazing sound quality.

Specifications

Width	453 mm
Depth	353 mm
Height	159 mm
Weight	14.6 kg

Turntable

Drive Method	Quartz lock, servo-type, direct drive
Turntable	Aluminium, die-casting diameter: 332 mm
Motor	3-phase, brushless DC motor
Braking System	Electronic brake
Rotation Speed	33⅓ rpm, 45 rpm
Rotation Adjustment Range	±8, ±16, ±50 %
Wow and Flutter	0.1 % or less WRMS (JIS WTD)
Signal-to-Noise Ratio	70 dB
Starting Torque	> 4.5 kgf・cm
Start Time	0.3 sec (at 33⅓ rpm)

Tone Arm

Arm Type	Universal type S-shape tone arm Gimbal-supported type bearing structure Static balance type
Overhang	15 mm
Effective Length	230 mm
Tracking Error	Tracking Error
Height Adjustment Range	6 mm
Stylus Pressure Variable Range	0-4 g (1 scale 0.1 g)
Proper Cartridge Weight	2.5-12 g (includes mounting materials)
Outputs	1 ANALOGUE (RCA)
