Monitor Audio CSS 230 - Super Slim 2 Inches Mounting Depth In-Ceiling Speaker (Each)
Monitor Audio CSS 230 - Super Slim 2 Inches Mounting Depth In-Ceiling Speaker (Each) - Image 2
Monitor Audio CSS 230 - Super Slim 2 Inches Mounting Depth In-Ceiling Speaker (Each) - Image 3
Monitor Audio CSS 230 - Super Slim 2 Inches Mounting Depth In-Ceiling Speaker (Each)
Monitor Audio CSS 230 - Super Slim 2 Inches Mounting Depth In-Ceiling Speaker (Each)
Monitor Audio CSS 230 - Super Slim 2 Inches Mounting Depth In-Ceiling Speaker (Each)
Category: Speaker

Monitor Audio CSS 230 - Super Slim 2 Inches Mounting Depth In-Ceiling Speaker (Each)

Key Features

  • Ultra-shallow mounting depth design (approx. 2 inch) ideal for installations with limited ceiling space

  • Compact driver architecture for reliable, balanced sound in residential and commercial settings

  • High-quality tweeter and mid/bass components engineered for clear vocals and detailed audio

  • Wide dispersion pattern for even sound coverage throughout the room

  • Flush, low-profile ceiling appearance for discreet integration with interior décor

  • Paintable grille lets you match the speaker to any ceiling colour or finish

  • Easy installation system designed for secure mounting in tight cavities

  • Designed for multi-room audio systems, background music, and home theatre environments

  • Durable construction for long-term performance and reliability

Ask a question
Delivery & Return

Description

Super Slim CSS 230

The CSS230 is a brilliantly innovative back-box design with an impressively shallow 50 mm (2″) mounting depth, custom-built to offer hi-fi levels of performance in spaces where no high-quality speaker has gone before.

Between 2″ stud frames or where pipework or cabling reduces mounting depth, the hybrid back-box construction and proprietary full-range driver array combine to deliver consistent audio quality with exceptional installation versatility.

The hybrid back-box provides the best of all worlds for the installer and the customer. Combined, the three proprietary 3″ mid-bass units achieve the bass output of a 6 1/2″ driver, all from a super-stealthy flush-fitted profile.

In keeping with Monitor Audio’s renowned design rigour, the crossover comprises high-quality film capacitors and low-loss inductors – selected for signal integrity – ensuring peerless audio detail and dynamics from a speaker of its size and application. When the CSS230 is in ‘ported’ mode, a fine gauze protects the acoustic system from dust ingress.

An optional square or premium grille can be used with this model.

Key Features

  • Super-slim mounting depth 50 mm (2″) designed to fit within 2” stud walls or where space is restricted
  • Hybrid CP ‘Controlled Performance’ style, enclosed or open back-box option provides flexible high-performance options and sound isolation in one (pictured right)
  • Driver configuration of three 3″ C-CAM bass/mid-range drivers in a radial array around a 19 mm C-CAM Gold Dome tweeter (fixed position) and high-quality crossover design offers Monitor Audio’s award-winning signature sound quality
  • Gold-plated sprung push terminals are reliable and easy to connect
  • Magnetically attached ‘Trim-less’ round and square grille options for discreet, reliable and easy servicing, flexible in-wall/ceiling installation, paintable to blend with décor
  • Patented Tri-Grip dog leg fixings – Reliable, robust and quick to install
  • Existing CB6 pre-construction bracket for easier system design and planning



Specifications

Frequency Response (-6 dB)
 100 Hz – 30 kHz sealed ‘CP’ (85 Hz – 30 kHz –open back)
Nominal Impedance
 8 ohms
Sensitivity (1W@1M)
 86 dB
Maximum SPL
 103.8 dBA
Power Handling (RMS)
 40 Watts – Full range (60 watts with crossover set to 100 Hz @ 12 dB/Octave)
Recommended Amplifier Requirements
 10 – 60 W
Drive Unit Complement
 3 x 3″ C-CAM cone bass-mid drivers
1 x 19 mm (3/4″) C-CAM Gold Dome tweeter
Crossover Recommendation
 100 Hz at a minimum of 12 dB/Octave (24 dB/Octave optimum)
Connection
 Gold Plated Sprung push terminals – for bare wire connection up to 4 mm(2)
Overall Diameter (Including Grille)
 250 mm (913/16″)
Overall Depth (Including Grille)
 54 mm (21/8″)
Cut-Out Hole Diameter
 211 mm (81/4″)
Mounting Depth
 50 mm (2″)
Optional Square Grille – Outer Dimensions
 249 x 249 mm (9 3/16″)
Fixing Type
 3-position Tri-Grip dog leg fixings
Construction Material
 ABS (UL94 rated, RoHS2 Compliant) – Painted steel grille
Weight
 2.88 kg (6 lb 5 oz)
Sold As
 Single Unit
