Magnat Signature IWT-162 In-Wall Speaker (Pair)

  • Key Features

    • 2-Way In-Wall Speaker Design
      Combines a dedicated woofer and tweeter in each speaker to produce balanced, full-range sound directly from the wall — ideal for music, movies, and distributed audio.

    • 6.5-Inch Woofer Drivers (Pair)
      Mid-size woofers deliver natural midrange and controlled bass for rich, detailed sound across a variety of audio content.

    • Separate Tweeters
      Dedicated tweeter units provide crisp, clear high frequencies with good detail and low distortion for enhanced vocal and treble performance.

    • Angled/Directional Acoustics
      Designed to project sound toward the listening area, improving off-axis clarity and imaging compared to standard flat in-wall speakers.

    • Wide Sound Dispersion
      Engineered to radiate audio broadly throughout the room, delivering consistent coverage for multiple seating positions.

    • Flush-Mount Installation
      Designed for secure in-wall mounting with included hardware for a clean, integrated appearance that blends into décor.

    • Paintable Grilles
      Low-profile grilles can be painted to match wall color and room décor for seamless visual integration.

    • Optimized Crossover Network
      Precisely balances transitions between woofer and tweeter for coherent, natural sound reproduction.

    • Durable Construction
      Built using quality materials for reliable, long-lasting performance in residential or commercial audio setups.

    • Versatile Application
      Ideal for distributed audio systems, background music zones, or front/centre/rear channels in home theatre installations.

    • Easy Connectivity
      Standard speaker terminals make connecting to amplifiers or AV receivers straightforward.

Description

 Signature IWT 162

  •  High-end chassis technology with ceramic/aluminum bass-midrange drivers and a coated fabric dome
  •  High load capacity with compact dimensions
  •  Uncomplicated installation thanks to a sophisticated mounting system
  •  Tonal structure is perfectly coordinated with the Signature series, it can be individually combined
  •  Treble level can be adjusted in 3 stages

The compact version for wall installation is the IWT 162, which features one woofer and a tweeter, yet still ensures a full-blooded sound. The 16 cm woofer with its aluminum/ceramic cone and a tweeter with coated fabric dome cater for the full frequency range down to 32 Hz. The treble level can be adjusted in three stages here as well, thereby enabling a wide range of installation positions. Measuring 320 x 220 mm with a mounting depth of 102 mm, the Signature IWT 162 doesn´t pose any problems during installation. It doesn´t require special housing and is perfectly accommodated in any drywall, and from a volume of 20 liters. The IWT 162 is suitable for use as a front speaker, as a fully-fledged front channel in a home cinema setup, as well as a luxurious rear channel speaker.



Specifications

  •  Principle 2-way in-wall/in-ceiling loudspeaker
  •  Drivers 1 x 6.5“ woofer-midrange 1 x 1“ dome tweeter
  •  Power Handling (RMS/Max.) 110 / 180 watts
  •  Sensitivity (2.8V/1m) 4 Ohms
  •  Frequency Response 32 – 28000 Hz
  •  Crossover Frequencies 3.100 Hz
  •  Recommended Amplifier Output 20 – 180 Watts
  •  Mounting depth 102 mm
  •  Outer Dimensions (WxH) 220 x 320 mm
  •  Cutting Out (WxH) 186 x 286 mm
  •  Weight 2.15 kg
