Description
Features
- Solid, dynamic bass for home cinemas up to 18 Hz
- Smallest THX Ultra 2-certified single subwoofer in the world
- 32 cm high-performance woofer supported by two 32 cm passive membranes
- Integrated Class D amplifier with 550 watts RMS and 1,100 watts of maximum power output
- Extremely sturdy MDF cabinet with solid 45 mm baffle
- All of the chassis have been specially developed for the Cinema Ultra set in order to meet the very strict requirements of the THX Ultra2 standard
- THX Ultra2-certified subwoofer for the Magnat Cinema Ultra set
- Top acoustic performance through individual components developed for high performance in all details
- Non-ventilated design to eliminate any air-flow noise at high levels
- Two long-stroke passive diaphragms adapted to the woofer and enclosure volume ensure deep, extended bass without any background noise
- 30 cm high-performance long-stroke woofer, 30 cm long-stroke passive diaphragms with self-Membrane
- Flow-optimised, highly stable die-cast aluminium cage to avoid compression effects and resonances
- Double-magnet high-power drive system with inductivity control ring for extremely low distortion
- Extremely large linear hub for maximum signal purity with large deflections
- Multiple-ventilated high-performance voice coil for high resilience
- Multiple-coated paper diaphragm and dust cap for ideal rigidity
- Low-loss rubber surrounds for woofer and passive diaphragms
- 8 screw fixings for firm anchoring in the baffle
- Very stable, braced MDF enclosure with particularly low-resonance, 45 mm thick baffle
- Class D high-performance amplifier specially developed for this subwoofer
- Class D technology and a switch-mode power supply ensure low heating and compact dimensions despite extremely high-efficiency performance
- Real-time limiter minimises distortions and prevents overloading
- Active frequency range equalisation according to the strict THX Ultra2 guidelines
- THX input and stereo inputs for flexible use in any surroundings
- Adjustable volume, phase and crossover frequency (in stereo mode)
- Auto stand-by and automatic switch-on for high user convenience
- Low stand-by power consumption < 1 Watt
- Front: black silk matt/body: textured film – anthracite
Specifications
- Brand Magnat
- PRINCIPLE THX Ultra2-certified active high-performance subwoofer Dual passive radiator
- EQUIPMENT 320 mm Woofer 2 x 320 mm passive radiator
- OUTPUT POWER (RMS/MAX.) 550 / 1100 watts
- FREQUENCY RESPONSE (18 – 200Hz
- CROSSOVER FREQUENCIES THX without filtering Line-Modus: 40-180 Hz
- PHASE 0° to 180° continuously variable
- DIMENSIONS (WXHXD) 468 x 461 x 460 mm 468 x 461 x 478 mm (incl. amplifier)
- WEIGHT 32.5 kg
- CABINET SURFACE Front: black silk matt/body: textured film – anthracite
