Klipsch DS-160CDT 6.5" In-Ceiling Speaker (Single)

The Klipsch DS-160CDT is a high-performance in-ceiling speaker designed to deliver refined, immersive audio while blending seamlessly into your space. It features a 6.5″ polypropylene woofer paired with a 1″ silk dome tweeter mounted on a Tractrix® horn for clear, efficient high frequencies. Thanks to Controlled Dispersion Technology™ (CDT), both the woofer and tweeter can be angled (up to ±15°) to better target your listening position, helping maintain on-axis clarity even when installation locations aren’t ideal. Installation is made simpler via Klipsch’s SkyHook™ tool-free system, which automatically secures the speaker once inserted, reducing setup time. The bezel-free magnetic grille keeps the look clean and discreet (and is paintable to match your ceiling). With a sensitivity of 91 dB and moderate power requirements, the DS-160CDT fits nicely into home theater or distributed audio systems, especially for height or surround applications.

Description

Featuring the Klipsch Signature Horn-Loaded performance at an incredible value, the DS-160CDT features a 6.5” Polypropylene woofer and a 1” Pivot Silk Dome tweeter mated to a round Tractrix® horn for dynamic acoustic performance. Utilizing the Sky Hook™ patented Cinch by Swarm Installation System, your install time is reduced by 75%.

Warranty:

2 years manufacturer’s warranty

Features:

6.5” Pivot Polypropylene woofer
1” Pivot Silk Dome tweeter
Patented Sky Hook™ Cinch by Swarm Installation System
Bezel-Free Magnetic Grille

Horn-Loaded Performance
Using the same Tractrix® horn technology and design principles of our premium architectural and box speaker lines, the all-new Klipsch Designer series provides true Klipsch power and performance. With a 6.5” Polypropylene woofer and a 1” Silk Dome tweeter mated to a round Tractrix® horn, the DS-160CDT brings dynamic, powerful, detailed Klipsch sound to your distributed audio, home theatre, or 2-channel system.

All-New, Bezel-Free Magnetic Grille

A completely redesigned power-coated magnetic steel grille eliminates the bezel for seamless, pristine integration into the living space.

Patent-Pending Skyhook™
Tool-Free Installation System
The exclusive installation system engages the dog legs automatically when the speaker is inserted into the cutout hole with a preset clamping force, eliminating the possibility of over-torquing. This fast, easy installation system reduces install time by up to 75%.

Controlled Dispersion Technology™
CDT technology allows for the tweeter and the woofer to be aimed at up to 15°, helping to ensure on-axis frequency response at almost any listening position.

Technical Specifications:

Frequency Response	77Hz – 20kHz +/- 3dB
High Frequency Driver	1″ (2.54cm) Silk Dome Tweeter mated to a round Tractrix® Horn
Low Frequency Driver	6.5” (16.51cm) Polypropylene Woofer
Sensitivity	91 dB @ 2.83V / 1m
Coverage Angle	100°
Power Handling	50W RMS/ 200W Peak
Impedance	8 Ohm Compatible
Enclosure Type	ABS/Infinite Baffle
Finish	Black Baffle/Frame, White Paintable Grille
Product Dimensions	9.2” W x 9.2” H x 4.5” D (23.3cm H x 23.3cm W x 11.3cm D)
Mounting Depth	4.34” (11.03cm)
Cutout Dimensions	8.3” (21.1cm)
Product Weight	7 lbs (3.18kg)
Included	Round Magnetic Grille
Installation Kit	IK-650-C II (Sold Separately)
Fire Rated Enclosure	ME-650-C (Sold Separately)
Built From	2017
