Description
The LX-NZ3 is a high-performance 4K UHD/HDR home theater projector with laser light source technology, BLU-Escent. Thanks to the BLU-Escent light source, it realizes a brightness of 3,000 lumens, so there is no need to pull the curtains every time. Plus, there is no need to care about the lamp life as it offers 20,000 hours of long life. Furthermore, the JVC’s original Auto Tone Mapping function automatically adjusts to deliver the optimum HDR image all the time. This projector will enhance your viewing experience to a new level.
Warranty:
2-year manufacturer’s warranty
Features:
- 4K resolution (3840 x 2160) and HDR (HDR10/HLG) compatible.
- With JVC’s original “Auto Tone Mapping” function, you can enjoy various HDR10 content with the best image quality without any difficult adjustments.
- Compact design for installation convenience: 41 cm by 34 cm, and less than 15 cm high (Approx. 16″ by 13-1/2″, and 5-3/4″ in height)
- Compatible with HDMI standards (4K/60P 4:4:4) and HDCP 2.2
- 4K input specs: Supports 4K/60p, 4:4:4/36bit, 4K/60p 4:2:2/36bit, and 4K/24p 4:4:4/36bit signals – for more vivid colors and subtle gradations
- Connectors: PC in, HDMI 1 with HDCP2.2 support, HDMI 2, USB Mini B, Trigger (12 V), USB Mini A (1.5 A power supply), and RS-232
- “BLU-Escent” Laser Light Source
- 3,000 lm brightness and 20,000-hour long life
- HDR (high dynamic range) for more realistic, dynamic images
- “Auto Tone Mapping” for pristine HDR10 picture quality
- 0.47-inch DMD for bright, high-definition 4k images
- Dynamic contrast ratio: Infinity:1
- Wide lens shift function: +/-60% vertical, +/-23% horizontal
- 1.6x high-resolution lens
- HDCP2.2 compatibility with HDMI 1 terminal to support video-streaming services and copyright-protected content, including UHD BD discs
- Available in 2 colors (black and white)
Technical Specifications:
| Device | 0.47″ DMD (1920 x 1080) |
| Resolution | 3840 x 2160 |
| Lens shift function | 60% vertical & +/-23% horizontal, motorized |
| Light source lamp | BLU-Escent (Laser Phosphor) |
| Lamp life | Approx. 20,000 hours in normal mode |
| Brightness | 3,000 lm |
| Contrast Ratio | Infinity:1 (Dynamic contrast ratio) |
| Video input terminals (back panel) | PC x 1(D-sub 15pin) |
| Control terminals | RS232C x 1(D-sub 9-pin) |
| Noise level | 29 dB (Eco) / 34 dB (Normal) |
| Power requirement | AC110 V-240 V, 50/60 Hz |
| Projector in use | 360W |
| Standby | 0.5W |
| Dimensions: W x H x D, mm | 405 x 145.8 x 341 |
| Dimensions: W x H x D, inches | 15-7/8 x 5-3/4 x 13-1/2 |
| Weight, kg | 6.3 |
| Weight, lbs | 13.86 |
