JVC KENWOOD DLA-NZ7BE D-ILA Home Theater Projector

    • The JVC DLA-NZ7BE is a premium home theater projector built to offer near-reference image quality, especially for cinema lovers who demand excellent contrast, rich colors, and future-proof features. It uses a trio of 0.69-inch native 4K D-ILA panels (4096×2160) with 8K “e-shift” technology, which shifts pixels to simulate higher resolution for sharper detail from 4K or 8K input sources. The light source is a BLU-Escent laser phosphor module, designed for long life (≈ 20,000 hours) and stable color performance. With its laser engine, high brightness (≈ 2,200 ANSI lumens), and strong contrast (native ~40,000:1, dynamic/infinite with laser modulation), it handles HDR content very well.

      The lens is a high-quality all-glass 65 mm / 17-element, 15-group design with motorized zoom (2×), motorized focus, and generous lens shift—about ±80% vertical, ±34% horizontal—making installation flexible (you can move the projector somewhat off-center without loss of image quality). It has HDMI 2.1 (x2, 48 Gbps) inputs with full HDCP 2.3 support, capable of accepting 8K/60 Hz and 4K/120 Hz signals. For movie buffs, it includes features like Frame Adapt HDR and Theater Optimizer to automatically adjust picture settings (dynamic tone mapping, etc.) to the screen size, room mounting, and content, helping maximize picture quality in real environments.

Description

The world’s first* home theater model to feature 8K60p/4K120p input. It is equipped with 8K/e-shift proprietary technology with 2-direction shift to reproduce an 8K-quality image from 4K signals. Compatible with the latest HDR10/HDR10+, with new Frame Adapt HDR Generation 2. BLU-Escent laser diode light source with new Light source control.

Warranty:

1-year manufacturer’s warranty

Features:

  • Clear Motion Drive supporting 4K60P (4:4:4) signal improves moving images more than ever
  • Color Management System with 6-axis Matrix
  • Eight settings of Installation Mode include Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, and Aspect; stored installation modes for various environments can be called up.
  • ISF C3 (Certified Calibration Controls) mode to reproduce excellent picture quality optimized for specific environments
  • Auto-Calibration Function using an optical sensor.
  • Wireless transmission options for 3D viewing

Technical Specifications:

Chip Type 0.69-inch 4K D-ILA device
Native Resolution 4096 x 2160
Display Resolution 8192 x 4320
Light Source
Type BLU-Escent Laser Diode
Life Time (Standard Mode) 20000 hours
Brightness 2200 lm
Dynamic Contrast ∞ : 1
Native Contrast 40000: 1
Modes Mode 1 (gentle), Mode 2 (strong), Off
HDR
HDR10+ Yes
Frame Adapt HDR Yes
Theatre Optimiser Yes
HLG Yes
Info Data MaxCLL and MaxFALL mastering data
HDR Picture Modes BT.709 / BT.2020 / DCI / HDR
Lens
Zoom 2x
Throw Ratio 1.43-2.92:1
Diameter 65mm
HDMI
Number of Connections 2
Data Rate 48Gbps
Video Signal Range
480p, 576p, 720p 60/50, 1080i 60/ 50, 1080p 120/ 100/ 60/ 50/ 30/ 25/ 24, 3840 x 2160p 120/ 100/ 60/ 50/ 30/ 25/ 24, 4096 x 2160p 120/ 100/ 60/ 50/ 30/ 25/ 24, 7680 x 4320p 60/ 50/ 30/25 /24
PC Signal Range VGA / SVGA / XGA / WXGA / WXGA+ / SXGA / WSXGA+ / UXGA / WUXGA / WQHD (60) / WQHD (120)
Input Level Adjustment Auto / Standard (16-235) / Enhanced (0-255) / Super White (16-255)
