JBL CSS8018 - 8″ 20W Full-Range In-Ceiling Speaker (Each)
JBL CSS8018 - 8″ 20W Full-Range In-Ceiling Speaker (Each) - Image 2
JBL CSS8018 - 8″ 20W Full-Range In-Ceiling Speaker (Each) - Image 3
JBL CSS8018 - 8″ 20W Full-Range In-Ceiling Speaker (Each)
JBL CSS8018 - 8″ 20W Full-Range In-Ceiling Speaker (Each)
JBL CSS8018 - 8″ 20W Full-Range In-Ceiling Speaker (Each)
Category: Speaker

JBL CSS8018 - 8″ 20W Full-Range In-Ceiling Speaker (Each)

Key Features

  • Full-range in-ceiling loudspeaker designed for commercial sound applications

  • 8-inch woofer delivers clear and balanced low and midrange audio

  • Integrated tweeter provides smooth high-frequency response

  • 20 W power handling suitable for background music and general paging systems

  • Wide dispersion pattern for even sound coverage throughout the listening area

  • Low-profile design with flush grille for discreet ceiling installation

  • Easy installation with standard cut-out and mounting hardware

  • Constructed for reliable performance in commercial environments

  • Durable enclosure and grille designed for long-term use

  • Suitable for offices, retail spaces, restaurants, and similar venues

Ask a question
Delivery & Return

Description

JBL CSS8018 – 8″ 20W Full-Range In-Ceiling Speaker (Each)

200 mm (8 in) Commercial Series Ceiling Speakers

JBL’s Commercial Series Ceiling Speakers provide excellent performance for paging and background music applications. High sensitivity across the product line provides maximum sound level, even at low tap settings.

Chin up, shoulders back, music blasting.

4. Long Battery Life

Extended Playtime: With up to 24 hours of wireless playtime, these headphones can easily last through long travel days or work shifts. Quick Charge Feature: A short charging time provides several hours of playback, making them convenient for on-the-go use.

Features

  • Very high 97 dB sensitivity
  • 10 Watt multi-tap transformer for 100V, 70V and 25V distributed lines
  • Fits CSS-BB8 backcan



Specifications

Drivers
 200 mm (8 in) Full-Range
Sensitivity
 97 dB (2k – 6k Hz)
Frequency Range (-10 dB) Driver/Grille Assembly
 50 Hz – 17 kHz
Installed in CSS-BB backcan
 90 Hz – 17 kHz
Coverage Angle
 110° conical
Driver Continuous Power Handling
 20 Watts
Transformer Taps
 10W, 5W, 2.5W
Transformer Taps
 10W, 5W, 2.5W, 1.3W
Transformer Taps
 10W, 5W, 2.5W, 1.3W
Transformer Insertion Loss
 1.5 dB Maximum
Transformer Connection
 Bare wire
Motor Mass
 283 g (10 oz)
Safety Agency
 Suitable for use in air handling spaces per UL1480, UL2043, NFPA 90 & NFPA 70, when installed with a corresponding UL Listed backcan, below. S7232/UL Listed, Signaling Speaker. Transformer UL registered per UL1876. In accordance with IEC60849/EN60849.
Matching CSS Backcan
 CSS-BB8 (0.15 cu ft)
Other Compatible Backcans
 MTC-81BB8 (0.26 cu ft) MTC-200BB6 (0.5 cu ft) MTC-300BB8 (1.0 cu ft)
Bolt Mounting Circle to Backcan
 4 points on 286 mm (11.25 in) diameter
Cutout DiameterOpen-back
 216 mm (8.5 in)
In CSS-BB backcan
 295 mm (11.7 in)
Depth (behind grille)
 73 mm (2.9 in)
Grille Diameter
 327 mm (12.9 in)
Net Weight (each)
 1.58 kg (3.5 lb)
Shipping Weight (ea)
 2.25 kg (5.0 lb)
Included Accessories
 4 pcs M4 x 40 mm sheet metal screws for attaching speaker/driver/transformer assembly to the corresponding backcan.
Power Rating
 See transformer taps
Transformer Taps
 100V Taps – 10W, 5W, 2.5W
70V Taps – 10W, 5W, 2.5W, 1.3W
25V Taps – 10W, 5W, 2.5W, 1.3W
Maximum SPL (1m)
 103 dB (top 25V/70V/100V tap)
Input Connectors
 Bare wire
Color
 White
Backcan
 formed steel (accessory)
Baffle/Rim
 Metal
Ceiling Cutout Size
 216 mm (8.5 in)
Plenum Usage
 Yes, with accessory backpack
