Revel Performa3 B112v2 12” 1000W Powered Subwoofer

The Revel Performa3 B112v2 is a high-end, full-fidelity powered subwoofer engineered to deliver deep, precise bass performance for premium home-theatre and stereo systems. At its heart lies a front-firing 12-inch coated-paper/pulp woofer with a 50 mm two-layer copper voice-coil and a double-stacked ceramic magnet assembly — offering around 82% more linear excursion compared to its predecessor. Revel Speakers+2Crutchfield+2 A built-in 1,000 W RMS amplifier drives the sealed-box enclosure to reach down to around 29 Hz (-3 dB) in normal mode, with even deeper extension in “Extended” mode (~23 Hz at -10 dB). Revel Speakers+2Crutchfield+2 The rear panel offers balanced (XLR) and unbalanced (RCA) inputs, variable low-pass crossover (50-150 Hz) with an LFE bypass, phase and gain controls, and an onboard parametric EQ for fine-tuning in the room. Crutchfield+1 Finished in premium high-gloss walnut, black or white, and weighing about 64.8 lbs (29.4 kg) with compact dimensions (~18.4″ H × 15.9″ W × 16.6″ D), it combines serious output with refined styling. Revel Speakers+1

Description

The Revel Performa3 B112v2 subwoofer sets a new standard for low frequency detail, musicality, and refinement. Featuring brute force visceral impact and high fidelity bass performance of unprecedented sophistication, the B112v2 is a must-have for home entertainment systems.

Warranty:

1-year manufacturer’s warranty

Features:

A 1000W 12″ Powered Subwoofer.
Features brute force, visceral impact, and high fidelity bass performance of unprecedented sophistication.
Suitable for low-frequency detail, musicality, and refinement.
An elegant cabinet, available in premium high-gloss black.
The strategically oriented internal bracing virtually eliminates unwanted cabinet vibration.

The Revel Performa3 B112v2 is the newest generation of Revel’s popular and successful B112 subwoofer, outfitted with the latest advancements in acoustic science and technology. At the heart of the B112v2’s engineering is a new and improved woofer with 82% more linear excursion than the B112. The transducer’s 19.2 lb Klippel-optimized magnet assembly features a double-stacked ceramic 5 magnet with a flared vent for improved airflow. As a result, turbulence is reduced, output is increased, and distortion is minimized. Additional cooling vents in the back plate increase power handling while reducing compression. The cast aluminum frame is fully vented to minimize acoustic losses from excessive back pressure. A 50mm two-layer copper voice coil wound on a high-heat-tolerant fiberglass former gives the transducer a significant range of travel. The parametric EQ is now localized onboard, rather than software-based, for easy adjustments in real time, as you listen. The elegant cabinet, available in premium high-gloss black, white, and walnut, is formed with contiguous wood layers to prevent splitting. Strategically oriented internal bracing virtually eliminates unwanted cabinet vibration, and thereby coloration. All Revel loudspeakers, including the B112v2, undergo double-blind, position-independent competitive tests during development, utilizing the latest psychoacoustic research and processes, to ensure that when you’re buying Revel, you’re buying the best.

Technical Specifications:

Driver Components	Coated paper/pulp cone with 50mm two-layer copper voice coil, vented ceramic 5 magnet assembly, and vented die-cast aluminum frame
Amplifier Power	1000 Watts RMS
Crossover Frequencies	50Hz – 150Hz low-pass filter with LFE bypass
Low Frequency Extension (normal mode)	24Hz (-10dB); 27Hz (-6dB); 29.5Hz (-3dB)
Low Frequency Extension (extended mode)	23Hz (-10dB); 26Hz (-6dB); 29Hz (-3dB)
Input Sensitivity	400mV (full power)/20k Ohms (balanced); 14k Ohms (unbalanced)
Enclosure Type	Sealed
Finishes	High-gloss walnut, black, and white
Height	18.44” (468mm)
Width	15.94” (404mm)
Depth	16.56” (420mm)
Weight	64.8 lbs (29.4kg)
Inputs	Balanced (XLR), unbalanced (RCA)
