Description
Revel in-ceiling loudspeakers draw upon the same research, resources, and unique perspectives that put all our loudspeakers in a class by themselves. Each model offers a standard-setting low sonic coloration and freedom from distortion over a wide dynamic range.
Warranty:
1-year manufacturer’s warranty.
Features:
-
Long-throw woofers with rubber surround provide high output with low distortion
-
A 1-inch (25mm) metal-dome tweeter with an integrated waveguide provides optimized response both on and off-axis
-
A high-order crossover network delivers accurate timbre reproduction
-
A sleek look integrates easily into any decor
Benefits:
A value-packed in-ceiling speaker from Revel
The Revel C283 might be the company’s least expensive 8″ in-ceiling speaker, but it shares some of the same technologies as Revel’s higher-end speakers. Its integrated tweeter waveguide provides great sound for listeners directly under the speaker, as well as those positioned off to the side. And its high-order crossover network allows the 8″ woofer and 1″ tweeter to blend together seamlessly.
The Revel C283 in-ceiling speaker features an integrated tweeter waveguide, which provides excellent on- and off-axis listening performance.
Space-saving long-term performance
Looking for a clear, natural sound without the bulk of a traditional box speaker? The C283 is a great choice for a stealthy stereo system or as an overhead effects channel of a surround sound system. A lifetime warranty ensures excellent long-term performance.
DIY installation
If this is a do-it-yourself install, check out my guide to installing in-ceiling speakers, along with our selection of in-wall speaker wire. You can paint the included magnetic grille to have your speaker blend in with your décor.
Technical Specifications:
| Height | Cutout Size 9.625″ (244.5mm) |
| Weight | 3.9 lbs (1.8kg) / Shipping Weight 5.9 lbs (2.71kg) |
| Low-Frequency Driver Components | 8″ Aluminum Cone, Cast-Polymer Frame Woofer |
| Mounting | Mounting Depth 5″ (130mm) |
| Recommended Amplifier Power | 10 – 100 Watts RMS |
| Sensitivity | 87dB |
| High-Frequency Driver Components | 1″ Aluminum-Dome Tweeter with Waveguide |
