Parasound ZAmp v3 Stereo Power Amplifier

Features:

Delivers 45 watts per channel at 8 ohms or 60 watts per channel at 4 ohms.
Compact 1U rack-mountable design ideal for home or professional audio systems.
High-current Class AB amplifier ensures clean, dynamic sound performance.
Automatic turn-on via 12V trigger or audio signal sensing.
Bridgeable to mono operation for increased power output (up to 90 watts).
Features gold-plated RCA inputs and speaker terminals for optimal connectivity.
Energy-efficient design with low standby power consumption.
Built-in protection circuitry for thermal, short-circuit, and overload safety.
Suitable for distributed audio, home theater, and custom installation setups.

Description

Parasound ZAmp v3 Stereo Power Amplifier

The Parasound ZAmp v3 Stereo Power Amplifier is a compact and versatile stereo power amplifier, offering high-quality amplification in a space-saving design. With 45 watts per channel at 8 ohms, the ZAmp v3 is perfect for small audio setups, custom installations, and multi-room systems. Its reliable performance and efficient operation make it a go-to choice for both home and commercial environments.

Main features of the Parasound ZAmp v3 Stereo Power Amplifier

Power Output: 45 watts per channel at 8 ohms
Design: Compact form factor ideal for tight spaces
Features: Bridgeable for 90 watts mono, 12V trigger input
Applications: Ideal for custom installations, multi-room audio, and small stereo setups
45 watts per channel into 8 Ω
60 watts per channel into 4 Ω
90 watts bridged into 8 Ω mono
Fully discrete circuitry with a toroidal power transformer
Low heat design
Headphone jack
Indicators for AC present and channel operating status
Automatic on/off by 9 – 12 V trigger
Gold-plated RCA input jacks and looping line output jacks
5-way speaker terminals
Compact chassis; 1 rack space high

The ZAmp v3 provides excellent sound quality in a compact design, making it a fantastic solution for versatile audio applications.

Great starter amp that can play louder than you can listen to!

Specifications of the Parasound ZAmp v3 Stereo Power Amplifier

Product Specifications
Continuous Power Output
8 Ω, both channels driven	45 watts RMS x 2 (20 Hz – 20 kHz)
4 Ω, both channels driven	60 watts RMS x 2 (20 Hz – 20 kHz)
8 Ω, minimum impedance	90 watts RMS x 1 (20 Hz – 20 kHz)
Current Capacity	12 amperes peak per channel
Frequency Response	5 Hz – 100 kHz, +0/-3 dB
Total Harmonic Distortion	< 0.07% at full power < 0.02% at typical levels
IM Distortion	< 0.05%
Dynamic Headroom	1.5 dB
Inter-channel Crosstalk	80 dB at 1 kHz 60 dB at 20 kHz
Input Impedance	33 kΩ
Input Sensitivity	600 mV; 1.5 V for full output
S/N Ratio	116 dB, input shorted, IHF A weighted
Dimensions	8-1/2″ W x 1-3/4″ H x 10″ D 2″ H with feet
Net Weight	7 lbs.
