Parasound JC5 Halo - 2 Channel Stereo Power Amplifier (Black)

High-current Class AB amplifier designed for refined, high-fidelity two-channel sound
Robust power delivery with ample headroom to drive a wide range of loudspeakers with authority and control
Balanced (XLR) and unbalanced (RCA) inputs for flexible connectivity to preamplifiers and source components
Independent gain controls per channel for precise matching and system tuning
Bridgeable mono mode for increased output when driving a single high-power channel
Dual high-capacity toroidal power transformers provide stable current reserves during dynamic peaks
Thermal and over-current protection circuitry for reliable, safe operation
Low distortion and noise floor for clear, natural, and detailed audio reproduction
Loop outputs for adding additional amplification or multi-room configurations
Solid metal chassis with black finish for durability and professional appearance
Front-panel metering and level controls for intuitive use and monitoring

Description

Power Output	Both Channels Driven 400 watts x 2, 8 Ω 600 watts x 2, 4 Ω
IM Distortion	< 0.04 %
DC Trigger Requirements	+9 Vdc to +12 Vdc, 5 mA
Power Output	Bridged Mode 1200 watts x 1, 8 Ω Bridged 4 Ω operation is not recommended
TIM	Unmeasurable
Audio Trigger Requirements	2 mV – 10 mV
Power measurement parameters are at 120 VAC	0.05% THD, RMS continuous power, full audio band (20 Hz – 20 kHz)
Inter-channel Crosstalk	> 87 dB at 1 kHz > 72 dB at 20 kHz
XLR Pin Identification	1 = Ground (Shield) 2 = Positive 3 = Negative (Return)
Current Capacity	90 amps peak, per channel
Input Impedance	Unbalanced: 33 kΩ Balanced: 66 kΩ,(33 kΩ per leg)
Dimensions	Width: 17-5⁄8″ (448 mm) Height without feet: 7-1⁄8″ (181 mm) Height with feet: 7-3/4″ ” (197 mm) Depth: 20″ (508 mm) Depth with cables: 21-1⁄2″ (546 mm)
Slew Rate	> 130 volts per microsecond
Total Gain	29 dB
Frequency Response	5 Hz – 100 kHz, +0/-3 dB 20 Hz – 20 kHz, +0/-0.25 dB
Input Sensitivity for 28.28 V Output into 8 Ω	Unbalanced: 1 V Balanced: 1 V per leg
Net Weight	73 lb. (33.1 kg)
Total Harmonic Distortion (THD)	< 0.05 % at full power < 0.03 % at typical listening levels
S/N Ratio	> 116 dB, input shorted, IHF A-weighted > 111 dB, input shorted, unweighted
Shipping Weight	90 lb. (40.8 kg)
Damping Factor	1000 at 20 Hz
Power Requirement	Standby: 1 Watt Idle (no music playing): 225 Watts Typical listening levels: 400 Watts Maximum: 1500 Watts
