Parasound JC3 Jr Halo - Phono Pre-Amplifier (Black)

High-performance phono stage designed to bring out the best from vinyl playback
Supports both Moving Magnet (MM) and Moving Coil (MC) cartridges with dedicated adjustable gain and loading settings
Ultra-low noise and distortion for cleaner, more detailed analog signal amplification
Precision RIAA equalisation ensures accurate, musical vinyl reproduction
Adjustable cartridge loading options including multiple impedance and capacitance settings for optimal matching
Balanced (XLR) and unbalanced (RCA) outputs for flexible connection to integrated amplifiers, preamps, or receivers
Robust power supply and premium internal components for stable performance and minimal interference
Front-panel gain control for quick adjustments based on cartridge type and performance
Compact, high-quality chassis designed to fit easily into home audio systems
Ideal for audiophiles and vinyl enthusiasts seeking refined detail, improved dynamics, and rich musical character

Description

Frequency Response	20-20Khz, +/- 0.2dB
Input Impedance	MM or MI: 47k Ω MC Variable: 50- 550 Ω
XLR Pin Identification	1 = Ground (Shield) 2 = Positive 3 = Negative (Return)
Total Harmonic Distortion	< 0.02% at 1 kHz
Output Impedance	Unbalanced: < 100 Ω Balanced: < 100 Ω per leg
AC Power Requirement	Standby: <1 watt Power On: 9 watts 115 VAC or 230 VAC 50 – 60 Hz
Signal to Noise Ratio, 40 dB Setting	>85dB, input shorted, IHF A-weighted >80dB, input shorted, unweighted
Input Capacitance	150 pF
Signal to Noise Ratio, 50 dB Setting	>89dB, input shorted, IHF A-weighted >84dB, input shorted unweighted
Input Sensitivity at 1 kHz, 4mV Input	40 dB: 4 mV for 450mV output 50 dB: 4 mV for 1.4 Volts output 60 dB: 4 mV for 4.25 Volts output
Dimensions	Width: 17-1/4” (437mm) Depth: 14-3/4” (375mm)
Signal to Noise Ratio, 60 dB Setting	> 94dB, input shorted, IHF A-weighted > 91dB, input shorted, unweighted
Input Sensitivity at 1 kHz, 1V Output	40 dB: 9 mV for 1.0 Volt output 50 dB: 3 mV for 1.0 Volt output 60 dB: 0.9 mV for 1.0 Volt output
Weight	Net: 13 lbs. (5.9 Kg) Shipping: 19 lbs. (8.6 kg)
Total Gain	40 dB / 50 dB / 60 dB (unbalanced output) 46 dB / 56 dB / 66 dB (balanced output)
