Cambridge Audio AX-A35 - Integrated Amplifier

Key Specifications & Features

Rated output: 35 W per channel into 8 Ω. manuals.cambridgeaudio.com+2Crutchfield+2
THD (un-weighted): < 0.01% @1kHz (80% rated power), < 0.15% over 20Hz-20kHz at 80% power. manuals.cambridgeaudio.com+1
Frequency response (-3dB): 5Hz – 50kHz. manuals.cambridgeaudio.com+1
Signal-to-Noise Ratio (ref 1W): > 82dB (unweighted). manuals.cambridgeaudio.com+1
Inputs: 4× RCA line inputs, 1× MM phono input (for turntables), 1× front-panel 3.5 mm AUX input. manuals.cambridgeaudio.com+1
Bass / Treble controls: Shelving controls for ±10dB at 100Hz / 10kHz. audioeden.com+1
Speaker/Output: Standard speaker binding posts, Rec out, USB 5V power output. Plush Technologies
Physical size & weight: Approx 83 mm (H) × 430 mm (W) × 335 mm (D); weight ~5.6kg. myhifi.hu+1
Standby power consumption: < 0.5W. manuals.cambridge

Description

The AXA35 boasts 35 watts of power per channel, an integrated moving magnet phono stage for turntable enthusiasts, a white display screen, and a ¼ inch headphone socket for private listening sessions

Warranty:

1-year manufacturer’s warranty

Features:

Power Output: 35 Watts (into 8 Ohms)
<0.01% @ 1kHz, 80% of rated power <0.15% 20Hz – 20kHz, 80% of rated power.
Frequency response (-3dB) 5Hz – 50kHz.
S/N ratio (ref 1W) >82dB (unweighted)
Input impedances. 47k ohms.
Power Amp damping factor. > 50.
260W.
Bass/Treble controls.

Enjoy stereo sound with your favorite pair of speakers and the Cambridge Audio AXA35 35W Integrated Amplifier. It outputs up to 35W per channel at 8 Ohms and features a dedicated phono MM input and four stereo RCA inputs. A 1/8″ aux jack lets you connect a compatible portable device, and the front-mounted 1/4″ headphone jack enables private listening. The AXA35 includes a remote control as an added convenience.
The AXA35 boasts 35 watts of power per channel, an integrated moving magnet phono stage for turntable enthusiasts, a white display screen, and a ¼ inch headphone socket for private listening sessions.

Technical Specifications:

POWER OUTPUT	35 Watts (into 8 Ohms)
THD (UNWEIGHTED)	<0.01% @ 1kHz, 80% of rated power <0.15% 20Hz – 20kHz, 80% of rated power
FREQUENCY RESPONSE (-3DB)	5Hz – 50kHz
S/N RATIO (REF 1W)	>82dB (unweighted)
INPUT IMPEDANCES	47k ohms
POWER AMP DAMPING FACTOR	> 50
MAX. POWER CONSUMPTION	260W
BASS/TREBLE CONTROLS	Shelving, ultimate boost/cut +/- 10dB @ 100Hz and 10kHz
STANDBY POWER CONSUMPTION	<0.5W
INPUTS	4x RCA, 1x Phono, 1x 3.5mm Aux input (front panel)
OUTPUTS	Speakers, Rec Out, USB 5V power
DIMENSIONS (HXWXD)	83 x 430 x 335mm (3.3 x 16.9 x 13.2”)
WEIGHT	5.6kg (12.3lbs)
IN THE BOX	AXA35 Integrated Amplifier, Power Cable, Remote Control, 2 x AAA Batteries
