Acoustic Energy AE120 – 3 Way Floor Standing Speaker (Pair) (Walnut Vinyl Veneer)

Acoustic Energy AE120

As the flagship of the range, the AE120 is the largest model in the 100 series and a true 3-way design. This speaker offers a big sound from a slim-line enclosure, tastefully styled to blend into a wide range of domestic environments. Twin bass drive units underpin the room-filling performance with a dedicated mid-range driver housed in its own enclosure, carefully designed to mitigate the harmful effects of rear wave reflections. Integrated within the perfectly matched Wide Dispersion Technology (WDT) waveguide, Acoustic Energy’s 25mm soft dome tweeter manages the high frequencies with controlled dispersion, high sensitivity and low distortion.

The 3-way crossover is impedance compensated to avoid the resonance issues which would otherwise slow bass delivery and colour mid-range performance. Particular attention has also been paid to the phase and time alignment for optimum integration and soundstage. The result is a loudspeaker offering smooth, wide dispersion of high frequencies with a clean mid-range and lightning-fast bass response. The inert cabinet enclosure is constructed from 15mm HDF and, like its smaller AE109 brother, is supplied mass-loaded to help dampen cabinet vibrations. The internal bracing system has been carefully tuned to reduce cabinet resonances and mid-range colouration, whilst the new AE120 benefits from a subtly styled, discrete black plinth to aid stability, further improving dynamics and stereo focus.

TWEETER

Acoustic Energy’s bespoke 25mm soft dome tweeter was designed in tandem with the 100 Series bass driver to offer optimum integration and tonal matching. Paired with our Wide Dispersion Technology waveguide, the crossover region between drive units is audibly seamless whilst the high-power neodymium motor assembly ensures reliable, distortion-free high-volume playback.

DRIVERS

The 130mm bass/mid driver used in the 100 Series has been developed with a high-power, long excursion motor to provide satisfying volume levels and bass extension from relatively compact enclosures. The doped paper cone enables a higher crossover point for smoother mid-range and seamless crossover with the tweeter, creating extremely high fidelity, detailed and above all musical sound reproduction.

CABINET

The 100 Series uses thin, 15mm high-density (HDF) enclosures with carefully tuned bracing, reducing harmful resonances whilst retaining body and substance from compact, practical cabinets. The rear slot porting* enhances smooth bass extension with minimal room impact, allowing easy placement. The AE109 and AE120 feature inert mass-loading for additional stability and acoustic damping; all models come supplied with slim magnetic grilles.

The latest adaptation of Acoustic Energy’s globally acclaimed 100 Series features an all-new, innovative design from the ground up…

The new 100 Series introduces a plethora of evolutionary improvements focused on refining the listening experience. All models (aside from AE108² Subwoofer) feature our WDT (Wide Dispersion Tweeter) waveguide for improved dispersion, now taking cues from our 500 Series, with mid/bass drivers moved closer to the tweeter. The drive units are all-new and designed in tandem to offer seamless integration along with improved response and power handling. Slot ports to the rear of each cabinet reduce chuffing & distortion, thanks to a new, tooled vent to further smooth airflow. Finally, as a first at this price point, the 100 Series uses HDF (High Density Fibreboard) construction to allow thinner cabinet walls with no loss in mass or stiffness – the result is larger internal volume providing deeper bass response for minimal external size increase.
This elegant, compact yet powerful range of speakers embodies all the qualities Acoustic Energy is renowned for, while taking advantage of everything we’ve learned in our continuous journey of development.
